Equipment structure: It is mainly composed of four parts: rack, feeding combination, blowing structure and control box.

Equipment features: simple operation, easy to use, no damage to peeling, high degree of automation, continuous production operation.

Working principle: After the onion is put into the storage hopper, the equipment starts, and the onion is automatically driven by the transmission mechanism to move forward while blowing skin processing.

Dimension: 4970*1510*1813 mm

Model: YCQP3000

Power: 3 kw / 380v / 50hz

Capacity: 2-3 T/H

Air compressor: 55 kw (Provided by user)

Air pressure: 0.6 Mpa

Weight: 1200 kgs
