Lifting bubble washer

Model:TSQPQX3000
Application:
Description:Lifting bubble washer is suitable for washing all kinds fruits and vegetables. Lifting system is convenient for cleaning machines.

Tel : 0086-18265879944

E-mail:info@zibounique.com
Send us your request and we will get in touch with you.

Introduction

Equipment voltage 380v / 50hz /3.5kw
1. The equipment box is made of SUS304 stainless steel plate with a thickness of δ=2.0mm, equipped with 1 bubbling machine and 1 set of built-in bubble pipes.
2. The bracket is a 50×50×1.5mm stainless steel square tube with a universal adjustment bolt at the bottom.
3. The conveying adopts stainless steel plate and belt, and the effective conveying width of plate and belt is 700mm.
4. The bottom of the equipment box is a trapezoidal bottom, which is convenient for drainage. Equipped with overflow and drain valve.
5. The conveying power is equipped with a horizontal reducer and a stainless steel protective cover. The frequency conversion speed regulation can appropriately adjust the conveying speed according to the processing progress.
6. The equipment is equipped with a circulating water spray pipe and a circulating water pump (one side of the box is equipped with a filter tank)
7. The equipment has a lifting function, which is convenient for cleaning, maintenance and maintenance.
8. The whole machine is made of stainless steel SUS304 except the motor and related parts.
9. The water injection volume of the whole machine is 1 cubic meter at a time, and the water source is filtered and recycled.

Parameter

Dimension: 3300*1350*1450 mm

Power: 3.5 kw / 380v / 50hz
